GA-B75M-HD3 REV: 1.0 triggers instant power loss repair Gigabyte b75m-hd3 Rev: 1.0 switch instantly enguishes auto power off, removes q54, solves the problem, lights up normally, and the maintenance is completed. Machine plate No: GA-B75M-HD3 REV: 1.0 Fault phenomenon: switch…
Gigabyte GA-H310M-D2VX is powered down, and the resistance of the replaced three-level tube is normal.
The power supply of Gigabyte P106 video card is short circuited. After replacing the C1048 capacitor, the fault is repaired.
Gigabyte GA-H61M-DS2 will restart several times after being triggered, and then it will light up. Remove the R220 and replace it with a new one. The machine will light up directly, and the fault will be removed.
Gigabyte GA-B85M-D2V does not trigger, IO is broken, replace one on the pallet, and repair the fault.
Gigabyte GA-H77-DS3H turns on the black screen and brushes the BIOS fault contact.
The mechanical revolution deep-sea ghost Z3 flash screen is directly connected to the fly power line. The machine no longer flashes, and the maintenance is over.
Asus H61M-E was restarted repeatedly, the pull-up resistor was replaced, and the fault was repaired.
After the triggering of Gigabyte B75-DS3V, power down immediately, replace the TQ9, or remove the TQ8, and the fault is removed.
